1단식
| 모델명 | 통과하중 | 데크폭(A) | 데크길이(B) | 피트높이(C) | 전동기(kw) | 유압실린더 | 상하조정각 |
|---|---|---|---|---|---|---|---|
| JDB-10 | 1000kg | 1800mm | 1000mm | 650mm | 1.2kw | 2-Φ 70 | ±5 |
| JDB-30 | 3000kg | 1720mm | 2000mm | 700mm | 2.2kw | 2-Φ 85 | ±7 |
| JDB-30 | 3000kg | 1720mm | 3000mm | 7500mm | 2.2kw | 2-Φ 90 | ±7 |
| JDB-50 | 5000kg | 2000mm | 2400mm | 800mm | 3.7kw | 2-Φ 100 | ±10 |
| JDB-90 | 9000kg | 2000mm | 3000mm | 850mm | 3.7kw | 2-Φ 120 | ±10 |
